2-way ball valves
Ball valves with GL screwthread made of chemically resistant PTFE. Maximum permissible atmospheric temperature 150°C, passing media can be as hot as 220°C.
The special construction allows the clamps to be used under pressures of up to 10 bar and also under vacuum. A further advantage is that they can be used as expansion/reduction adapters to connect tubing of different diameters. For easy tubing connection we recommend the accessory Bola laboratory screwthread connection which can be ordered separately.
Toote variatsioonid
| Catalog number | PK | Bore | Length | Material | Thread | Kogus | |
|---|---|---|---|---|---|---|---|
| 9.207 307 | 1.00 | 8 mm | 90 mm | PTFE | GL 25 | ||
| 9.207 305 | 1.00 | 3 mm | 50 mm | PTFE | GL 14 | ||
| 9.207 306 | 1.00 | 4 mm | 80 mm | PTFE | GL 18 | ||
| 9.207 308 | 1.00 | 12 mm | 100 mm | PTFE | GL 32 |
