Advanced Inverted Microscope for Industrial and Material science AE2000 MET
The AE2000 MET series is the ideal microscope for industrial quality inspection and material science. Different objective options allow applications in brightfield & darkfield or examination of larger samples.
- Infinity Optics [CCIS®]
- Observation Tube Siedentopf Type, Trinocular-/Phototube 45°, F.N. 20, 360° swivelling
- Interpupillary Distance 48-75 mm
- Eyepieces High-Eyepoint N-WF 10x/20 mm with diopter adjustment on both eyepieces and rubber eyecups
- Side facing quintuple nosepiece
- Objectives CCIS LM Plan achromat DIN 5X, 10X, 20X, 50X
- M32 with adapters to W 4/5″ x 1/36″ (RMS standard)
- Mechanical stage 280 x 192 mm surface with metal round and oval stage inserts
- X and Y range of 50 x 50 mm
- External lamphouse, Illumination 12 V/100 W halogen with intensity control and sleeping mode
- Universal power supply 100-240 V (CE)
- Blue filter, Allen hexagonal key, vinyl dust cover and power cord
Toote variatsioonid
| Catalog number | PK | Depth | Depth stage | Dimensions (WxDxH) | Height | Light type | Max. voltage | Min. voltage | Power supply | Revolving nosepiece | Stage (WxD) | Tube | Type | Weight | Width | Width stage | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6.287 153 | 1.00 | 673 mm | 192 mm | 280 x 673 x 345 mm | 345 mm | Halogen | 240 V | 100 V | 100 ... 240 V | 5-fold | 280 x 192 mm | Trinocular | AE2000 MET | 13 kg | 280 mm | 280 mm |
