Advanced Polarization Microscope for Laboratory, Research and Education, BA310 POL
An extremely powerful yet affordable Polarization microscope for Transmitted light samples. Designed for the examination of birefringent samples from petrography and mineralogy, and can also be used for the synthetic materials in industry.
- Infinity Optics [CCIS®]
- Observation Tube Siedentopf Type, Trinocular-/Phototube 30°, F.N. 20
- Interpupillary Distance 55-75 mm
- Eyepieces High-Eyepoint N-WF 10x/20 mm with dioptre adjustment on both eyepieces and rubber eyecups
- Rotatable analyzer 360°, Bertrand lens 0,5X and slot for compensators
- Reversed quadruple revolving nosepiece, single centrable positions
- Objectives CCIS® EC Plan Achromatic Strain-free 4x, 10x, 40x-S, 60x-S
- 360° circular rotating stage, 160 mm diameter, 1° increments, 0,1°vernier scale and lockable
- Achromat swing-out condenser N.A. 0.90/0.13 (strain-free) with iris diaphragm and rotatable polarizer
- Koehler illumination quartz halogen 6V/30 W with intensity control
- Universal power supply 100-240 V (CE)
- Empty insertion plate, blue filter, power cord, Allen hexagonal key, vinyl dust cover and spare fuse
Toote variatsioonid
| Catalog number | PK | Condenser | Depth | Ø stage | Dimensions (WxDxH) | Height | Light type | Max. voltage | Min. voltage | Power supply | Revolving nosepiece | Tube | Type | Weight | Width | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7.920 271 | 1.00 | Abbe N.A. 0.90/0.13 | 400 mm | 160 mm | 220 x 400 x 452 mm | 452 mm | Halogen | 240 V | 100 V | 100 ... 240 V | 4-fold | Trinocular | BA310 POL | 10.4 kg | 220 mm |
