Compact Immersion circulator ICC basic
Compact immersion thermostat for tempering of liquids in open or covered vessels. The adjustable pressure and suction pump allows the ICC basic to be used for internal or external applications. A holding clamp for attaching the circulator to a bath is included. An optional cooling coil can be connected to the unit for temperature control below or near the ambient temperature. The ICC basic can be easily transported with the carrying handle and safely stored with the integrated stand.
Complete packages with all necessary components (bath vessels, covers, bath bridges, pump connection sets and cooling coils) are also available.
- Visual and acoustic warning functions for excess temperature, sub-level and over-level
- LED display for temperature and pump adjustment
- Menu navigation via push and turn buttons
- Adjustable safety circuit
- Calibration option
- USB/RS 232 interface
Toote variatsioonid
| Catalog number | PK | Depth | Heating capacity | Height | IP code | Max. flow rate | atr_llg_max_suction_pressure | Max. temperature | Max. voltage | Min. temperature | Temp. Stability | Temperature | Type | Type of display | Width | Dimensions (WxDxH) | Power supply | Temperature | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6.264 529 | 1.00 | 200 mm | 2000 W | 340 mm | IP 21 | 0.2 bar | 150 °C | 230 V | -10 °C | ±0,02 K | RT | ICC basic | LED | 145 mm | 145 x 200 x 340 mm | 230 V, 50...60 Hz | RT+10 ... 150 °C |
