Compact vacuum oven Vacutherm™ VT 6025
For the gentle and rapid drying or heat treatment of temperature sensitive substances and components in the electronics, pharmacy, cosmetics and biochemistry fields. With double glazed safety glass door window, very low external casing temperature, freely adjustable overheat cut-out with separate temperature sensor, Kelvitron® microprocessor controlled temperature controller and pull-out, non-tilting shelves with end stops.
- External dimensions (W x D x H): 480mm x 450mm x 600mm
- Internal dimensions (W x D x H): 300mm x 307mm x 275mm
- Interior volume: 25L
- Usable height above shelf: 120mm
- Nominal temperature: 200°C
- Ultimate vacuum: 1 x 10-² mbar
- Power supply: 230V 50/60Hz
- System of protection: IP 20
Toote variatsioonid
| Catalog number | PK | Temperature | Depth int. | Ext. depth | Ext. height | Ext. width | Height int. | Int. width | IP code | Max. no. of inserts | Max. temperature | Max. voltage | Min. temperature | Nominal capacity | Rated capacity | Type | Ultimate vacuum | Weight | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 9.883 480 | 1.00 | RT | 307 mm | 450 mm | 600 mm | 480 mm | 275 mm | 300 mm | IP 20 | 4 | 200 °C | 230 V | -15 °C | 25 l | 1300 W | VT 6025 | 0.01 mbar | 58 kg |
