Conductivity cell probes TetraCon® 325

For all pocket measuring devices for analog measuring cells from the 3xx series, as well as all inoLab laboratory measuring devices for analog measuring cells.

Standard conductivity cell probe TetraCon^® 325:
4-pole cell with integral temperature sensor.

Special conductivity cell probe TetraCon^® 325/C:
As TetraCon^® 325, 4-pole cell with integral temperature sensor, but with sensor head made of chemically resistant PEEK.

Toote variatsioonid

PK	Catalog number	Cable length	Cell constant	Shaft length	Material shaft	Max. pressure	Max. temperature	Min. temperature	Shaft Ø	Temperature	Temperature sensor	Type
1.00	7.008 434	3 m	0.475 1/cm	120 mm	Epoxy	2 bar	80 °C	5 °C	15.3 mm	5 ... 80 °C	NTC 30 kOhm	TetraCon® 325-3
1.00	6.229 561	1.5 m	0.475 1/cm	120 mm	Epoxy	2 bar	80 °C	5 °C	15.3 mm	5 ... 80 °C	NTC 30 kOhm	TetraCon® 325/C
1.00	7.008 436	10 m	0.475 1/cm	120 mm	Epoxy	2 bar	80 °C	5 °C	15.3 mm	5 ... 80 °C	NTC 30 kOhm	TetraCon® 325-10
1.00	7.008 438	20 m	0.475 1/cm	120 mm	Epoxy	2 bar	80 °C	5 °C	15.3 mm	5 ... 80 °C	NTC 30 kOhm	TetraCon® 325-20
1.00	7.008 437	15 m	0.475 1/cm	120 mm	Epoxy	2 bar	80 °C	5 °C	15.3 mm	5 ... 80 °C	NTC 30 kOhm	TetraCon® 325-15
1.00	7.008 435	6 m	0.475 1/cm	120 mm	Epoxy	2 bar	80 °C	5 °C	15.3 mm	5 ... 80 °C	NTC 30 kOhm	TetraCon® 325-6
1.00	9.704 081	1.5 m	0.475 1/cm	120 mm	Epoxy	2 bar	80 °C	5 °C	15.3 mm	5 ... 80 °C	NTC 30 kOhm	TetraCon® 325
