Conductivity measuring cells InLab®, graphite
4-electrode measuring cells made of graphite with integrated temperature sensor and fixed cable. Ideal for samples with normal and high conductivity.
Toote variatsioonid
| Cable length | Cell constant | Conductivity | Connection plug | Shaft length | Material shaft | Max. temperature | Min. temperature | Catalog number | Shaft Ø | Temperature | Temperature sensor | Type | PK | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.2 m | 0.57 1/cm | Mini-DIN | 120 mm | Epoxy | 100 °C | 0 °C | 9.041 447 | 12 mm | 0 ... 100 °C | NTC 30 kOhm | InLab® 731 | 1.00 | |||
| 2 m | 0.57 1/cm | Mini-DIN | 120 mm | Epoxy | 100 °C | 0 °C | 9.041 441 | 12 mm | 0 ... 100 °C | NTC 30 kOhm | InLab® 731-2m | 1.00 | |||
| 1.8 m | 0.57 1/cm | - | 120 mm | Epoxy | 100 °C | 0 °C | 7.636 591 | 12 mm | 0 ... 100 °C | NTC 30 kOhm | InLab® 738 | 1.00 |
