Density meter DMA 501
Density meter for measuring of chemicals, pharmaceuticals, cosmetics and food. Suitable for samples with difficult properties like paste, inhomogeneous, sedimenting and particulate samples or aerosol sprays.
The DMA 501 contains all relevant concentration tables and formulas for calculating product specific parameters and the results are displayed in the appropriate unit. Automatic filling and measuring with the optional available industrial peristaltic pump possible.
- Camera image of the measuring cell (U-view™) for viewing the correct sample filling, whereby potential filling errors due to inhomogeneous samples, gas bubbles or paticles are automatically detected with the FillingCheck™ function
- Splash-proof front
- Fanless temperature control of the sample
- User-defined layouts of the measurement display with result outputs for individual requirements
- Documentation and traceability of data
- Elimination of external influences through the implementation of a standardised sample handling
- Integrated temperature and humidity sensor
- Integrated pressure sensor for adjustment
- Automatic full-range viscosity correction of results
- Minimal sample volume: approx. 1 ml
- 3 years warranty
Toote variatsioonid
| Catalog number | PK | Accuracy | Accuracy | Depth | Dimensions (WxDxH) | Height | Interfaces | Max. voltage | Measured range | Min. voltage | Power supply | Resolution | Type | Waranty | Weight | Width | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6.313 796 | 1.00 | ±0.001 g/cm³ | 0.001 g/cm³ | 375 mm | 265 x 375 x 180 mm | 180 mm | 1 x Ethernet, 3 x USB, 1 x RS232 | 240 V·AC | 0 ... 3 g/cm³ | 100 V·AC | 100 ... 240 V·AC, 47 ... 63 Hz | 0.0001 g/cm³ | DMA 501 | 3 years | 13.5 kg | 265 mm |
