Double diaphragm pumps DMP 1/4″ KNTC Ex
Highly resistant diaphragm made of TPV (EPDM-PP) and TFM (PTFE). Conductive version approved according to ATEX directive 2014/34/EU, category 4. Housing made of PVDF, carbon fiber reinforced.
Toote variatsioonid
| Type | Height mm | Temp. max. °C | Depth mm | Operating pressure bar | Material | Membrane | Width mm | Flow rate l / min. | Weight kg | Delivery head mWS | Catalog number | PK | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DMP 1/4'' KNTC Ex | 203 | 90 | 183 | 8 | PVDF | TPV (EPDM-PP) + TFM (PTFE) | 107 | 21 | 19 | 80 | 4.684 001 | 1.00 |
