Heated bath circulators HBC basic, with stainless steel bath
Heated bath circulators with stainless steel bath for operating temperatures up to 250 °C. Easy switching between internal and external control. With integrated cooling coil and powerful pressure and suction pump in a housing made of temperature and chemical resistant plastic. The large surface of the radiator allowes for an optimum heat exchange, even heating of the medium and very fast heat-up times. The bath is easy to clean and has a drain valve with hose connection on the front for draining the bath. Can be operated with flammable liquids.
- Adjustable safety circuit
- Simple menu navigation with push buttons and rotary knobs
- Visual and audible warning functions
- USB/RS 232 interface
- With large, easy-to-read LED display
Toote variatsioonid
| Catalog number | PK | Depth opening | External dimensions (WxDxH) | Ext. depth | Ext. height | Ext. width | Heating capacity | IP code | Material bath | Max. flow rate | atr_llg_max_suction_pressure | Max. temperature | Max. voltage | Max. volume bath | Min. temperature | atr_llg_min_volume_bath | Power supply | Temp. Stability | Temperature | Temperature | Type | Type of display | Volume bath | Weight | Width opening | Bath depth | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 9.720 319 | 1.00 | 82 mm | 275 x 500 x 406 mm | 500 mm | 406 mm | 275 mm | 2500 W | IP 21 | Stainless steel | 0.45 bar | 250 °C | 230 V | 7 l | -10 °C | 5 l | 230 V, 50...60 Hz | 0,02 K | RT | RT+10 ... 250 °C | HBC 5 basic | LED | 5 ... 7 l | 17 kg | 172 mm | 150 mm | |||
| 9.720 321 | 1.00 | 82 mm | 275 x 500 x 456 mm | 500 mm | 456 mm | 275 mm | 2500 W | IP 21 | Stainless steel | 0.45 bar | 250 °C | 230 V | 11 l | -10 °C | 8 l | 230 V, 50...60 Hz | 0,02 K | RT | RT+10 ... 250 °C | HBC 10 basic | LED | 8 ... 11 l | 18 kg | 172 mm | 150 mm |
