Heating mantles Electrothermal® MHM-200
Heating mantle has a “V”-shaped design for large, pear-shaped and round-bottom flasks. The bottom opening allows 60° funnels of various diameters to be accommodated. Coiled heating element provides optimal heat transfer. Control heat throughout the mantle using three separate electrical circuits (top, middle, and bottom), each controlled with its own dial switch.
- Cool-to-the-touch design with powder-coated aluminium casing
- Indicator lamps for “power on” and “heat on” operation
Scope of supply: Heating mantle, three sets of integrated support rod clamps, power cords with UK and EU plugs
Toote variatsioonid
| Depth | Dimensions (WxDxH) | Height | Max. temperature | Max. voltage | atr_llg_no_of_heating_points | No. of heating zones | Catalog number | Plug type | Power supply | Rated capacity | Type | atr_llg_vessels_capacity | Width | PK | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 485 mm | 485 x 485 x 300 mm | 300 mm | 450 °C | 230 V | 1 | 3 | 4.011 144 | EU/UK | 230 V, 50...60 Hz | 3600 W | MHM-200-22L | 22000 ml | 485 mm | 1.00 | ||
| 485 mm | 485 x 485 x 300 mm | 300 mm | 450 °C | 230 V | 1 | 3 | 4.011 142 | EU/UK | 230 V, 50...60 Hz | 2350 W | MHM-200-12L | 12000 ml | 485 mm | 1.00 | ||
| 485 mm | 485 x 485 x 300 mm | 300 mm | 450 °C | 230 V | 1 | 3 | 6.282 660 | EU/UK | 230 V, 50...60 Hz | 2350 W | MHM-200-10L | 10000 ml | 485 mm | 1.00 | ||
| 485 mm | 485 x 485 x 300 mm | 300 mm | 450 °C | 230 V | 1 | 3 | 4.672 211 | EU/UK | 230 V, 50...60 Hz | 3600 W | MHM-200-20L | 20000 ml | 485 mm | 1.00 |
