Jaw Crushers BB
For rapid and gentle coarse grinding and crushing of hard, brittle and tough materials. Continuous gap adjustment with scale and zero-point adjustment for wear compensation. Excellent performance with enhanced final fineness, robust construction, fitted with quick-release hopper, receiver with safety switch and casing. Standard model is supplied with manganese steel breaking jaws.
- High throughput
- Continuous gap width adjustment
- Braking motor with safety switch
- Easy cleaning of grinding chamber
Toote variatsioonid
| Max. throughput | Plug type | Type | PK | Depth | Height | IP code | Max. voltage | Catalog number | Rated capacity | Weight | Width | atr_llg_max_final_fineness | Dimensions (WxDxH) | Power supply | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 300 kg/h | EU | BB-200 | 1.00 | 900 mm | 1160 mm | IP 54 | 400 V·3/N/PE | 9.519 120 | 1500 W | 300 kg | 450 mm | 2 mm | 450 x 900 x 1160 mm | 400 V·3/N/PE, 50 Hz Hz | ||
| 600 kg/h | EU | BB 300 | 1.00 | 1600 mm | 1450 mm | IP 54 | 400 V·3/N/PE | 9.739 093 | 3000 W | 700 kg | 670 mm | 5 mm | 670 x 1,600 x 1450 mm | 400 V·3/N/PE, 50 Hz Hz |
