Laboratory refractometer Abbemat Advanced
The Abbemat Advanced achieves precise and consistent measurement results in demanding and automated laboratories. The laboratory refractometer can be easily implemented into multi-parameter measuring systems or equipped with an optional autosampler. Networked, secure user and data management is possible via the optional lab execution software AP Connect.
- Easy integration into IT networks
- Interfaces: Ethernet, 3 x USB-B, CAN
- Data storage for 10000 measurement results, 400 products
- Accurate temperature measurement at the surface of the prism
- Customisable touchscreen interface with instant pass/fail feedback based on set limits
- Sample-specific measurement settings save time and avoid errors
- Over 200 pre-installed measurement scales
- Long-life LED light source
- Scratch-resistant sapphire prism with 25-year warranty
Toote variatsioonid
| Accuracy Number | Depth | Dimensions (WxDxH) | Height | Max. temperature | Max. voltage | Measured range | Min. temperature | Min. voltage | Catalog number | Power supply | Resolution | Temperature | Type | Weight | Width | PK | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 330 mm | 225 x 330 x 115 mm | 115 mm | 105 °C | 240 V | 4 °C | 100 V | 4.713 221 | 100 ... 240 V, 50/60 Hz | 4 ... 105 °C | Abbemat 5201 | 3.5 kg | 225 mm | 1.00 | |||||
| 330 mm | 225 x 330 x 115 mm | 115 mm | 70 °C | 240 V | -10 °C | 100 V | 4.713 220 | 100 ... 240 V, 50/60 Hz | 10 ... 70 °C | Abbemat 5101 | 3.5 kg | 225 mm | 1.00 | |||||
| 330 mm | 225 x 330 x 115 mm | 115 mm | 40 °C | 240 V | -20 °C | 100 V | 4.713 219 | 100 ... 240 V, 50/60 Hz | -20 ... 40 °C | Abbemat 5001 | 3.5 kg | 225 mm | 1.00 |
