Laminar Flow Clean Benches, Type Airstream®, horizontal
The new generation of ESCO Airstream horizontal and vertical laminar flow benches offer optimal product protection by achieving ISO Class 5 conditions inside the cabinet.
Features:
- Energy-efficient DC ECM motors
- Stable and self-compensating airflow
- Sentinel Gold microprocessor control
- Control panel to easily monitor the operating parameters
- Standby mode reduces power consumption while maintaining the ISO class 5 conditions inside the work bench
- Visual and audible alarms
- Side windows made of safety glass
- Standard working space height vertical/horizontal benches: 689 mm/573 mm
- Additional working space heights on request.
- ULPA filter with long service life and protection mesh
- Pre-filter EU3
- ISOCIDE antimicrobial coating on all painted surfaces minimizes contamination
- Apparatus for UV lamp with timer (UV lamp and protective cover must be ordered separately)
Options on request:
Stands, electrical sockets (4.662 021), front covers with UV lamp, IQ/OQ
Please order stands separately.
Toote variatsioonid
| Catalog number | PK | Depth int. | External dimensions (WxDxH) | Ext. depth | Ext. height | Ext. width | Height int. | Illumination | Internal dimensions (WxDxH) | Int. width | Max. air volume flow | Max. voltage | Min. voltage | Noise level | Power supply | Rated capacity | Type | Weight | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4.658 999 | 1.00 | 596 mm | 1,340 x 784 x 1,270 mm | 784 mm | 1270 mm | 1340 mm | 573 mm | 1139 Lux | 1,160 x 596 x 573 mm | 1160 mm | 1117 m³/h | 240 V·AC | 220 V·AC | 55.8 db(A) | 220 ... 240 V·AC, 50/60 Hz , 7.3 A | 171 W | LHG-4AG-F8 | 145 kg | ||
| 4.659 000 | 1.00 | 596 mm | 1,645 x 784 x 1,270 mm | 784 mm | 1270 mm | 1645 mm | 573 mm | 984 Lux | 1,405 x 596 x 573 mm | 1405 mm | 1400 m³/h | 240 V·AC | 220 V·AC | 58.4 db(A) | 220 ... 240 V·AC, 50/60 Hz , 7.6 A | 211 W | LHG-5AG-F8 | 167 kg | ||
| 6.285 840 | 1.00 | 596 mm | 1,035 x 784 x 1,270 mm | 784 mm | 1270 mm | 1035 mm | 573 mm | 1045 Lux | 855 x 596 x 573 mm | 855 mm | 834 m³/h | 240 V·AC | 220 V·AC | 53.2 db(A) | 220 ... 240 V·AC, 50/60 Hz , 7 A | 140 W | LHG-3AG-F8 | 100 kg | ||
| 4.659 001 | 1.00 | 596 mm | 1,950 x 784 x 1,270 mm | 784 mm | 1270 mm | 1950 mm | 573 mm | 1221 Lux | 1,770 x 596 x 573 mm | 1770 mm | 1683 m³/h | 240 V·AC | 220 V·AC | 60.0 db(A) | 220 ... 240 V·AC, 50/60 Hz , 8 A | 249 W | LHG-6AG-F8 | 212 kg |
