Multi-Flask Shaker VKS 75 B control
Big heavy-duty shaker for high loads also during continuous operation (floor installation only). With digital display and programmable control with Touch-Display. Further accessories on request.
Scope of supply: Basic device without shaking plate, without rack system
-
Specifications
Speed range:
30 … 200 rpm in steps of 5 -
Orbit or stroke: 26 mm (model A)
50, 36, 60 or 80 mm (model B) - Max. loading: max. 75 kg
- Platform (W x D): 760 x 600 mm
- Overall (W x D x H): 1050 x 835 x 250 mm
- Weight: 110 kg
- Supply requirements: 100 … 240 V, 50/60 Hz
Toote variatsioonid
| Depth | Display | Height | IP code | Max. speed | Max. voltage | Min. speed | Min. voltage | Catalog number | Plug type | Shaking stroke | Type | Type of movement | Weight | Width | With timer | PK | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 835 mm | Digital | 250 mm | IP 21 | 200 1/min | 240 V | 30 1/min | 100 V | 9.838 403 | EU | 50 mm | VKS 75 B control | Reciprocal | 110 kg | 1050 mm | Yes | 1.00 |
