Oxygen sensor DurOx® 325
For use with Oxi 3xxi, ProfiLine Oxi 1970i, ProfiLine 3205, 3210, 3310.
Membrane-covered oxygen sensor with low flow requirement and removable cage guard, for field applications (fish farm revival pools) and for educational purposes.
- Ready to measure – no polarisation time
- IMT compensation via two integral temperature sensors
- Service life with one electrolyte filling approx. 6 months
- Minimal flow requirement
- No zero current
- Sensor is watertight (IP 68 – 2)
- Standard with 3m cable and watertight plug
- Standard with calibration/storage vessel OxiCal® -D
- Standard with cage guard SK-D
Toote variatsioonid
| Catalog number | PK | Cable length | Concentration | Material shaft | Max. temperature | Min. temperature | Partial pressure | Saturation | Temperature | Temperature sensor | Type | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 9.920 045 | 1.00 | 3 m | 0 ... 50 mg/l (20 °C) | POM | 40 °C | 0 °C | 0 ... 1250 mbar (20 °C) | 0 ... 600 % (20 °C) | 0 ... 40 °C | NTC 30 kOhm | DurOx® 325 |
