Piston pump LLG-uniVACUUPUMP 1

The portable piston pump LLG-uniVACUUPUMP 1 has been developed for vacuum and pressure applications in the laboratory, in particular in the field of Life Science. Typical applications for this low-cost vacuum pump are the single funnel filtration of aqueous and buffered solutions, SPE, as well as any applications where no harmful gases are conveyed. The LLG-uniVACUUPUMP 1 operates oil-free and can also be used as a compressor to a pressure up to 3.3 bar. This allows you, for example, pressure filtration, if vacuum filtration is not sufficient.
Not recommended for pumping organic, acidic, or basic vapours.

Advantages:

• Dry-running technology for physical applications
• Can be used as a vacuum pump and compressor
• Cost-effective alternative for water pumps
• Sound suppressor for quiet operation
• Compact, light weight and portable
• Oil-free, suitable for continuous operation
• Suction/pressure connection: hose nozzle DN 6 for hose inner diameter 6 mm

Scope of supply: Pump, incl. 2 hose clamps, EU + UK-plug power cord

• Specifications
• Pump speed 50/60 Hz at atmospheric pressure: 9.2/11 l/min
• Final pressure: 292 mbar
• Max. overpressure: 3.3 bar
• Max. operating gas temperature: 60 °C
• Permissible ambient temperature: 10 … 40 °C
• Suction/pressure connection: DN 6
• Noise emission: <45 dB(A)
• Motor power: 25 W
• Dimensions (W x D x H): 194 x 114 x 191 mm
• Weight: 2.0 kg
• Power supply: 230 V/50 Hz
• IP code: IP 20
• Warranty: 3 years
