Platform scales EOC

Thanks to rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (laboratory, production, quality control, commissioning etc.). The KERN Communication Protocol (KCP) permits searching and remote control of the balance using external control devices or computers.

Large backlit LCD display

Weighing plate stainless steel, painted steel base

Silicone-coated aluminium load cell

Level indicator and levelling feet for precise levelling

Flip/Flop display device (W×D×H): 268×115×80 mm

Interfaces: RS-232

Scope of supply: Platform scale, benchtop stand incl. wall mount for display device, protective working cover

Toote variatsioonid

Adjusting program	Depth	Depth weighing plate	Dimensions (WxDxH)	Height	Linearity	Material housing	Max. load	Max. voltage	Min. voltage	Catalog number	Plug type	Power supply	Readability	Reproducibility	Type	Waranty	Weighing plate (WxD)	Weight	Width	Width weighing plate	PK
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.006/0.015 kg	Plastic	60/150 kg	240 V	100 V	4.660 155	EU/UK/CH	100 ... 240 V	0.002/0.005 kg	0.002/0.005 kg	EOC 100K-3	2 years	300 x 300 mm	6 kg	300 mm	300 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.003 kg	Plastic	12 kg	240 V	100 V	4.660 157	EU/UK/CH	100 ... 240 V	0.001 kg	0.001 kg	EOC 10K-3	2 years	300 x 300 mm	7 kg	300 mm	300 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.06/0.15 kg	Plastic	60/150 kg	240 V	100 V	4.660 150	EU/UK/CH	100 ... 240 V	0.02/0.05 kg	0.02/0.05 kg	EOC 100K-2	2 years	300 x 300 mm	6 kg	300 mm	300 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0,0006/0,0015 kg	Plastic	6/15 kg	240 V	100 V	4.660 159	EU/UK/CH	100 ... 240 V	0.0002/0.0005 kg	0.0002/0.0005 kg	EOC 10K-4	2 years	300 x 300 mm	6 kg	300 mm	300 mm	1.00
External	400 mm	400 mm	500 x 400 x 120 mm	120 mm	±0.15/0.3 kg	Plastic	150/300 kg	240 V	100 V	4.660 161	EU/UK/CH	100 ... 240 V	0.05/0.1 kg	0.05/0.1 kg	EOC 300K-2	2 years	500 x 400 mm	9 kg	500 mm	500 mm	1.00
External	500 mm	500 mm	600 x 500 x 150 mm	150 mm	±0.06/0.15 kg	Plastic	60/150 kg	240 V	100 V	4.660 153	EU/UK/CH	100 ... 240 V	0.02/0.05 kg	0.02/0.05 kg	EOC 100K-2XL	3 years	600 x 500 mm	19 kg	600 mm	600 mm	1.00
External	500 mm	500 mm	950 x 500 x 60 mm	60 mm	±0.06/0.15 kg	Plastic	60/150 kg	240 V	100 V	4.660 154	EU/UK/CH	100 ... 240 V	0.02/0.05 kg	0.02/0.05 kg	EOC 100K-2XXL	3 years	950 x 500 mm	17 kg	950 mm	950 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.003 kg	Plastic	12 kg	240 V	100 V	4.660 158	EU/UK/CH	100 ... 240 V	0.001 kg	0.001 kg	EOC 10K-3A	2 years	300 x 300 mm	7 kg	300 mm	300 mm	1.00
External	400 mm	400 mm	500 x 400 x 120 mm	120 mm	±0.006/0.015 kg	Plastic	60/150 kg	240 V	100 V	4.660 156	EU/UK/CH	100 ... 240 V	0.002/0.005 kg	0.002/0.005 kg	EOC 100K-3L	2 years	500 x 400 mm	9 kg	500 mm	500 mm	1.00
External	400 mm	400 mm	500 x 400 x 120 mm	120 mm	±0.015/0.03 kg	Plastic	150/300 kg	240 V	100 V	4.660 163	EU/UK/CH	100 ... 240 V	0.005/0.01 kg	0.005/0.01 kg	EOC 300K-3	2 years	500 x 400 mm	9 kg	500 mm	500 mm	1.00
External	400 mm	400 mm	500 x 400 x 120 mm	120 mm	±0.0015/0.003 kg	Plastic	15/35 kg	240 V	100 V	4.660 166	EU/UK/CH	100 ... 240 V	0.0005/0.001 kg	0.0005/0.001 kg	EOC 30K-4	2 years	500 x 400 mm	9 kg	500 mm	500 mm	1.00
External	400 mm	400 mm	500 x 400 x 120 mm	120 mm	±0.03 kg	Plastic	120 kg	240 V	100 V	4.660 151	EU/UK/CH	100 ... 240 V	0.01 kg	0.01 kg	EOC 100K-2A	2 years	500 x 400 mm	9 kg	500 mm	500 mm	1.00
External	400 mm	400 mm	500 x 400 x 120 mm	120 mm	±0.015/0.03 kg	Plastic	15/35 kg	240 V	100 V	4.660 165	EU/UK/CH	100 ... 240 V	0.005/0.01 kg	0.005/0.01 kg	EOC 30K-3L	2 years	500 x 400 mm	9 kg	500 mm	500 mm	1.00
External	400 mm	400 mm	500 x 400 x 120 mm	120 mm	±0.003/0.006 kg	Plastic	30/60 kg	240 V	100 V	4.660 169	EU/UK/CH	100 ... 240 V	0.001/0.002 kg	0.001/0.002 kg	EOC 60K-3L	2 years	500 x 400 mm	9 kg	500 mm	500 mm	1.00
External	500 mm	500 mm	600 x 500 x 150 mm	150 mm	±0.15/0.3 kg	Plastic	150/300 kg	240 V	100 V	4.660 162	EU/UK/CH	100 ... 240 V	0.05/0.1 kg	0.05/0.1 kg	EOC 300K-2L	3 years	600 x 500 mm	19 kg	600 mm	600 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.015/0.03 kg	Plastic	15/35 kg	240 V	100 V	4.660 164	EU/UK/CH	100 ... 240 V	0.005/0.01 kg	0.005/0.01 kg	EOC 30K-3	2 years	300 x 300 mm	6 kg	300 mm	300 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.003/0.006 kg	Plastic	30/60 kg	240 V	100 V	4.660 167	EU/UK/CH	100 ... 240 V	0.001/0.002 kg	0.001/0.002 kg	EOC 60K-3	2 years	300 x 300 mm	7 kg	300 mm	300 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.015 kg	Plastic	60 kg	240 V	100 V	4.660 168	EU/UK/CH	100 ... 240 V	0.005 kg	0.005 kg	EOC 60K-3A	2 years	300 x 300 mm	7 kg	300 mm	300 mm	1.00
External	400 mm	400 mm	500 x 400 x 120 mm	120 mm	±0.03/0.06 kg	Plastic	30/60 kg	240 V	100 V	4.709 473	EU/UK/CH	100 ... 240 V	0.01/0.02 kg	0.01/0.02 kg	EOC 60K-2L	2 years	500 x 400 mm	9 kg	500 mm	500 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.003/0.006 kg	Plastic	3/6 kg	240 V	100 V	4.660 170	EU/UK/CH	100 ... 240 V	0.001/0.002 kg	0.001/0.002 kg	EOC 6K-3	2 years	300 x 300 mm	6 kg	300 mm	300 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.03/0.06 kg	Plastic	30/60 kg	240 V	100 V	6.289 197	EU/UK/CH	100 ... 240 V	0.01/0.02 kg	0.01/0.02 kg	EOC 60K-2	2 years	300 x 300 mm	7 kg	300 mm	300 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.0015 kg	Plastic	6 kg	240 V	100 V	4.660 171	EU/UK/CH	100 ... 240 V	0.0005 kg	0.0005 kg	EOC 6K-4A	2 years	300 x 300 mm	6 kg	300 mm	300 mm	1.00
External	300 mm	300 mm	300 x 300 x 110 mm	110 mm	±0.0015/0.003 kg	Plastic	15/35 kg	240 V	100 V	4.681 431	EU/UK/CH	100 ... 240 V	0.0005/0.001 kg	0.0005/0.001 kg	EOC 30K-4S	2 years	300 x 300 mm	6 kg	300 mm	300 mm	1.00
