PLR compressed air laboratory stirrers up to 30 l for use in potentially explosive atmospheres, without tachometer
PLR compressed air laboratory stirrers are designed for all kinds of standard mixing tasks. The vane type, air-driven motor offers a high power density and is significantly lighter and smaller than an equivalent electric motor.
General specifications:
- operating pressure max. 6 bar
- air consumption 260 l/min. at 6 bar
- power output 200 W at 6 bar
- clockwise rotation
- ATEX certification
Basic models include:
- all-stainless steel housing
- continuously adjustable speed control valve
- support arm diam. 14 mm
- snap connection for NW 5
- output shaft L x diam. 26 x 10 mm
The viscosity data are intended as a guideline.
Toote variatsioonid
| Catalog number | ATEX certification | Idle speed | Max. operating pressure | Max. Viscosity | Nominal torque | Operating press bar | PK | Rated capacity | Type | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 9.778 952 | Ex II 2G Ex h IIC T5 Gb | 870 1/min | 6 bar | 70000 mPa·s | 5.3 Ncm | 6 bar | 1.00 | 200 W | PLR 12 | ||
| 9.778 951 | Ex II 2G Ex h IIC T5 Gb | 1900 1/min | 6 bar | 50000 mPa·s | 3.5 Ncm | 6 bar | 1.00 | 200 W | PLR 11 | ||
| 9.778 954 | Ex II 2G Ex h IIC T5 Gb | 580 1/min | 6 bar | 100000 mPa·s | 10.4 Ncm | 6 bar | 1.00 | 200 W | PLR 28 | ||
| 9.778 950 | Ex II 2G Ex h IIC T4 Gb | 15000 1/min | 6 bar | 1000 mPa·s | 0.3 Ncm | 6 bar | 1.00 | 200 W | PLR 10 |
