Polarisation microscope Panthera TEC POL

Powerful polarisation microscope for all material sciences. Maximum flexibility for all applications in polarisation microscopy, suitable for transparent as well as opaque samples from the education sector and industrial quality assurance.

• Tube type Siedentopf, swiveling
• Widefield oculars for spectacle wearers with diopter adjustment on both oculars
• CCIS^® Plan achromatic objectives UC PL (strain-free)
• Reversed coded nosepiece with single centering holes
• Bertrand lens and slot for compensators
• Focusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polariser
• Illumination acc. to Köhler, with interchangeable illuminator
• Motic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicator
• Coaxial coarse and fine focusing system with tension adjustment
• Compact, built-in mechanical stage
• Integrated power supply with sleep mode
• Visual camera output
• USB 2.0 for external camera power

Scope of supply: Microscope, dust cover, power cord, Allen key, blue filter, halogen bulb, LED module, adjustable key for nosepiece, interference color chart, screws for metal extension support

• Specifications
• Inclination Tube: 25°
• Angle of rotation Tube: 360°
• Eyepieces: Widefield UC-WF10X/22 mm
• Nosepiece: Quintuple
• Objectives: 4X/0.1 (AA 30.5 mm), 10X/0.25 (AA 17.4 mm), 40X/0.65/S (AA 0.6 mm), 60X/0.8/S (AA 0.35 mm)
• Interpupillary distance:
  Trinocular light split: 48 … 75 mm
  Fixed 50:50
• Condenser: N.A. 0.90/0.13 Abbe-Condenser
• Illumination: 3 W LEDs / 30 W Halogen
• Fine focus increment:
  Focusing stroke: 2 µm
  25 mm
• Dimensions Stage (W x D):
  Stage size (Ø): 1 increment, 0.1 skale
  160 mm
• Dimensions (W x D x H): 410 x 300 x 395 mm
• Net weight: 9.8 kg
• Power supply: 110 … 240 V, 50 / 60 Hz
