Safety Storage Cabinets S-CLASSIC-90 with Wing Doors

safe and approved storage of hazardous materials in workrooms

type proved according to EN 14470-1, fire resistance 90 minutes

GS-approved

outer body made of sheet steel, colour light grey (RAL 7035), interior with chemical resistant surface

lockable doors with cylinder lock (integration into a locking system possible)

adjusting aids for compensation for uneven floor

ventilation connection (NW 75)in the cabinet ceiling

standard door open arrest system holds doors open, safe and convenient storage and removal

Shelves, height adjustable (32 mm increments), load capacity 75 kg (evenly distributed load), bottom collecting sump with perforated insert as a first storage level. Capacity bottom collecting sump: 33 litre (model width 1200 mm), 22 litre (model width 600 mm).

Supplied with: Safety Storage Cabinet S-CLASSIC-90 Model S90.196.120.WDAS or S90.196.060.WDAS incl. interior equipment with 3 shelves, bottom collecting sump with perforated insert

A wide variety of cabinet versions is available. Please enquire.

Toote variatsioonid

Catalog number	PK	Colour body	Colour doors	Depth int.	External dimensions (WxDxH)	Ext. depth	Ext. height	Ext. width	Height int.	Internal dimensions (WxDxH)	Int. width	Standard	Type	Version cabinet	Weight
6.286 542	1.00	Yellow	Yellow	524 mm	596 x 616 x 1,968 mm	616 mm	1968 mm	596 mm	1742 mm	450 x 524 x 1,742 mm	450 mm	DIN EN 16121/16122	S90.196.060.WDAS	Tall cabinet	281 kg
6.286 540	1.00	Yellow	Yellow	524 mm	896 x 616 x 1,968 mm	616 mm	1968 mm	896 mm	1742 mm	750 x 524 x 1,742 mm	750 mm	DIN EN 16121/16122	S90.196.090.WDAS	Tall cabinet	371 kg
6.260 928	1.00	Light grey	Light grey	524 mm	1,196 x 616 x 1,968 mm	616 mm	1968 mm	1196 mm	1742 mm	1,050 x 524 x 1,742 mm	1050 mm	DIN EN 16121/16122	S90.196.120.WDAS	Tall cabinet	451.5 kg
6.269 868	1.00	Light grey	Light grey	524 mm	596 x 616 x 1,968 mm	616 mm	1968 mm	596 mm	1742 mm	450 x 524 x 1,742 mm	450 mm	DIN EN 16121/16122	S90.196.060.WDAS	Tall cabinet	281 kg
6.286 539	1.00	Light grey	Light grey	524 mm	896 x 616 x 1,968 mm	616 mm	1968 mm	896 mm	1742 mm	750 x 524 x 1,742 mm	750 mm	DIN EN 16121/16122	S90.196.090.WDAS	Tall cabinet	371 kg
6.270 910	1.00	Yellow	Yellow	524 mm	1,196 x 616 x 1,968 mm	616 mm	1968 mm	1196 mm	1742 mm	1,050 x 524 x 1,742 mm	1050 mm	DIN EN 16121/16122	S90.196.120.WDAS	Tall cabinet	451.5 kg
