Sand bath SD with performance control and permanent connection

For continuous operation. Electrical sand bath with stepless power control. Anodised aluminium alloy hotplate. Excellent uniform temperature distribution over the entire heating surface. The sand bath frame is tightly screwed onto the hotplate so that the sand is in direct contact with the hotplate. Useful depth 50 mm. Stainless steel controller housing, with painted central section. Height-adjustable feet.

Toote variatsioonid

Depth int.	Display	Ext. depth	Ext. height	Ext. width	Heating capacity	Height int.	Int. width	Max. temperature	Max. voltage	Min. temperature	Operation	Catalog number	Temperature	Type	Type of display	Weight	PK	External dimensions (WxDxH)	Internal dimensions (WxDxH)	Power supply	Temperature	Kogus
590 mm	Analogue	592 mm	220 mm	442 mm	4000 W	50 mm	440 mm	370 °C	400 V·3/N/PE	5 °C	Rotary knob	6.230 863	RT	SD 9-400	Without display	27 kg	1.00	442 x 592 x 220 mm	440 x 590 x 50 mm	400 V·3/N/PE	RT+5 ... 370 °C
590 mm	Analogue	592 mm	220 mm	442 mm	4000 W	50 mm	440 mm	370 °C	230 V	5 °C	Rotary knob	9.645 805	RT	SD 9-230	Without display	27 kg	1.00	442 x 592 x 220 mm	440 x 590 x 50 mm	230 V	RT+5 ... 370 °C
