Spectrophotometer 7415 nano

For accurate, fast and reproducible measurement of sample volumes from 0.5 µl to 5 µl. Programmed for the measurement of nucleic acid concentration and purity as well as protein assays. The direct application of the sample on the measuring head eliminates the need for cuvettes or sample dilution. Single measurements are performed in less than 6.5 seconds. Fast cleaning of the measuring optics simply by wiping off. Customized Android-based user interface to control the instrument, set measurement modes and retrieve results. Ethernet and USB interfaces for transfer of results, updates and printer connection as well as networking with cloud services.

• Ideal for DNA, RNA and protein determination
• Only 0.5 µl sample volume required
• For DNA concentrations up to 2 ng/µl
• 7″ color touch screen
• Multilingual user interface
• 10 GB internal memory for methods and results
• 3 years warranty, also on the xenon lamp
• Stainless steel measuring head with quartz lens

• Specifications
• Wavelength range: 198 … 1000 nm
• Wavelength accuracy:
  Spectral bandwidth: ±2 nm
  5 nm
• Absorbance accuracy:
  Transmittance range: ±0.01 at 1.0 A
  0 … 199.9 %
• Concentration range: 2 … 6000 ng/µl dsDNA
• DNA measurement modes: dsDNA, ssDNA, RNA, Oligonucleotides, 260/280, 260/230, variable ratio
• Protein measurement modes: BCA, Bradford, Lowry, Biuret, direct UV
• Light source: Xenon lamp
• Dimensions (W x D x H):
  Weight: 275 x 400 x 220 mm
  7.7 kg
• Power supply: 100 … 240 V, 50 … 60 Hz
