Stirrer Bearings, PTFE
The sealing rings on these bearings ensure a perfect sealing. The ground joint no longer sticks, the danger of breaking is reduced and the cone can be removed easily from the socket. A special gasket made of PTFE and an FPM o-ring which is compressed by a GL screw cap provide a good sealing of the stirrer shaft. This gasket can be exchanged after wearing. Suitable for vacuum, perfect bearing for stainless steel, glass and BOLA Stirrer Shafts.
Toote variatsioonid
| Catalog number | PK | Bore | Cone[s] | Overall length | Thread | Kogus | |
|---|---|---|---|---|---|---|---|
| 6.088 058 | 1.00 | 10 mm | NS29/32 | 72 mm | GL25 | ||
| 6.233 200 | 1.00 | 8 mm | NS19/26 | 65 mm | GL25 | ||
| 6.232 941 | 1.00 | 16 mm | NS45/40 | 86 mm | GL32 | ||
| 6.900 411 | 1.00 | 6 mm | NS19/26 | 63 mm | GL18 | ||
| 6.253 704 | 1.00 | 10 mm | NS24/29 | 70 mm | GL25 | ||
| 6.251 738 | 1.00 | 8 mm | NS24/29 | 69 mm | GL25 | ||
| 6.076 532 | 1.00 | 8 mm | NS29/32 | 74 mm | GL25 | ||
| 6.800 985 | 1.00 | 10 mm | NS45/40 | 80 mm | GL25 | ||
| 6.087 538 | 1.00 | 6 mm | NS29/32 | 72 mm | GL18 |
