Syringe Pumps Legacy®
The simple and easy to use Legacy® pumps are a high value solution for delivering precise and smooth flow in research and production applications. The KDS 100 pump gives customers the most cost effective solution for infusing fluids. Alternatively, the KDS 200 gives advanced features with RS232 and TTL interfaces and can be daisy chained together to create a pumping network. KDS 220 holds up to 10 syringes.
- Vibration Elimination System
- Flow Direction Indicator
- Fast Forward/Reverse
- Power Recovery Diagnostics
- Syringe Library
- Flow Rate Selection
- Volume Dispense Mode
- Direct Entry Syringe Diameter
- Optional: Foot Pedal Interface, NIST Certificate, Alarm
KDS 100 Single-Syringe Infusion Pump: Economical pump combining precision flow with outstanding ease-of-use and exceptional durability.
KDS 101 Two-Syringe Nanoliter Pump: For microdialysis and similar applications which require virtually pulseless flow at very low flow rates.
KDS 200 Two-Syringe Infusion Pump: Programmable pump for daisy chain connection. Feature-laden and with a broad speed range and a wide range of syringe sizes it meets the requirements of most laboratory applications.
KDS 220 Multi-Syringe Infusion Pump: For applications requiring multiple syringes. This pump has been modified to hold up to 10 syringes.
Toote variatsioonid
| Type | Dimensions (W x D x H) mm | Weight kg | Flow rate | For syringes | Catalog number | PK | Kogus | |
|---|---|---|---|---|---|---|---|---|
| KDS 100 | 230 x 153 x 130 | 2 | 0.1 µl/h ... 423 ml/h | 1 (10 µl ... 60 ml) | 6.290 324 | 1.00 | ||
| KDS 101 | 230 x 153 x 130 | 2 | 0.001 µl/min ... 0.351 ml/min | 2 (10 µl ... 10 ml) | 6.291 640 | 1.00 | ||
| KDS 220 | 280 x 235 x 140 | 4 | 0.001 µl/h ... 8824 ml/h | ≤10 (10 µl ...10 ml)≤6 (40 ml ...60 ml)≤4 (100 ml ...140 ml) | 4.672 169 | 1.00 | ||
| KDS 200 | 280 x 235 x 140 | 4 | 0.001 µl/h ... 8824 ml/h | 2 (10 µl ... 140 ml) | 6.311 356 | 1.00 | ||
| KDS 200 | 280 x 235 x 140 | 4 | 0.001 µl/h ... 8824 ml/h | 2 (10 µl ... 140 ml) | 6.237 902 | 1.00 |
