Temperature/pressure data logger EBI 12-TP237
Robust, sterilizable temperature/pressure data logger for process validation and routine or batch control in the washer-disinfector and steam sterilizer.
- Hose connection and M10x1 internal thread
- Wireless measurement
- Real-time data transmission
- PT1000 temperature probe and piezoresistive pressure sensor
- Temperature probe (Ø 1.95 mm) rigid, axial
- Needle length 20 mm
- Memory for up to 2 x 33440 measured values
- Factory calibration certificate: 0 °C, 60 °C, and 134 °C / 100 mbar, and 3100 mbar at 25 °C, 3100 mbar at 134 °C
Scope of supply: Temperature/pressure data logger
Toote variatsioonid
| Ø | Height | IP code | Max. temperature | Min. temperature | Catalog number | Type | Weight | PK | Max. air pressure | Min. air pressure | Resolution | Air pressure | Battery/rechargeable battery | Dimensions (ØxH) | Temperature | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 48 mm | 32 mm | IP 68 | 140 °C | 0 °C | 4.691 835 | EBI 12-TP237 | 120 g | 1.00 | 4000 mbar | 1 mbar | 0.01 °C | 1 ... 4000 mbar | 3.6 V, Lithium | 48 x 32 mm | 0 ... 140 °C |
