Heating bath thermostats CC, with polycarbonate bath

The transparent polycarbonate baths are suitable for temperatures up to 100 °C. All models come with a Pilot ONE immersion circulator mounted on a bath bridge. With a pump adapter, the combinations can be used for both externally closed and externally open (with optional level control) temperature applications. The devices are equipped with overtemperature and low level protection. The electronic upgrade function “E-grade” allows a simple and cost-effective functional expansion at any time.

Powerful pressure/suction pump

Large and full colour 5.7″ TFT Touchscreen

Simple menu navigation in 13 languages

Programmer with calendar/clock functions

Ethernet, RS232, and USB interface

Pt100 external sensor connection

2-point calibration for control sensors

Safety class III (FL) acc. to DIN 12876

Toote variatsioonid

Catalog number	PK	Bath depth	Depth opening	External dimensions (WxDxH)	Ext. depth	Ext. height	Ext. width	Heating capacity	IP code	Material bath	atr_llg_max_suction_capacity	atr_llg_max_suction_pressure	Max. temperature	Max. voltage	Max. volume bath	Min. temperature	Min. voltage	Operation	Power supply	Temp. Stability	Temperature	Type	Type of display	Volume bath	Weight	Width opening
9.859 207	1.00	150 mm	321 mm	333 x 520 x 335 mm	520 mm	335 mm	333 mm	2.1 kW	IP 20	PC	22 l/min	0.4 bar	100 °C	240 V	18 l	25 °C	200 V	Touchscreen	200 ... 240 V, 50/60 Hz	±0,02 K	25 ... 100 °C	CC-118A	TFT	18 l	8 kg	275 mm
9.859 204	1.00	150 mm	210 mm	147 x 407 x 330 mm	407 mm	330 mm	147 mm	2.1 kW	IP 20	PC	22 l/min	0.4 bar	100 °C	240 V	6 l	25 °C	200 V	Touchscreen	200 ... 240 V, 50/60 Hz	±0,02 K	25 ... 100 °C	CC-108A	TFT	6 l	6 kg	130 mm
9.859 205	1.00	150 mm	310 mm	147 x 507 x 330 mm	507 mm	330 mm	147 mm	2.1 kW	IP 20	PC	22 l/min	0.4 bar	100 °C	240 V	7.5 l	25 °C	200 V	Touchscreen	200 ... 240 V, 50/60 Hz	±0,02 K	25 ... 100 °C	CC-110A	TFT	7.5 l	6 kg	130 mm
9.859 206	1.00	150 mm	161 mm	333 x 360 x 335 mm	360 mm	335 mm	333 mm	2.1 kW	IP 20	PC	22 l/min	0.4 bar	100 °C	240 V	12 l	25 °C	200 V	Touchscreen	200 ... 240 V, 50/60 Hz	±0,02 K	25 ... 100 °C	CC-112A	TFT	12 l	8 kg	275 mm
9.859 203	1.00	150 mm	110 mm	147 x 307 x 330 mm	307 mm	330 mm	147 mm	2.1 kW	IP 20	PC	22 l/min	0.4 bar	100 °C	240 V	4.4 l	25 °C	200 V	Touchscreen	200 ... 240 V, 50/60 Hz	±0,02 K	25 ... 100 °C	CC-106A	TFT	4.4 l	5 kg	130 mm
