Coating thickness gauge, digital, TE-F
For non-magnetic coatings on iron and steel. The Offset-Accur function allows you to adjust the instrument precisely on the locally measured range by a two-point calibration. This results in a higher accuracy of approx. 1 % of the measured value.
- Selectable measuring units: µm, ml
- Auto-Power-Off
- Battery operation
- Data interface RS-232
Scope of supply:
Coating thickness gauge, external sensor, base plate, calibration foils, carrying case
- Precision
- Standard: 3 % of measured value or ± 2,5 µm
- Offset-Accur: 1 % of measured value or ± 1 µm
- Minimal base thickness: 0.3 mm
Toote variatsioonid
Measuring range µm | Depth | Dimensions (WxDxH) | Height | Catalog number | Power supply | Readability | Width | PK | Kogus | |
---|---|---|---|---|---|---|---|---|---|---|
100/1250 | 65 mm | 131 x 65 x 28 mm | 28 mm | 4.691 204 | 4 x 1,5 V AAA | 0,1/1 µm | 131 mm | 1.00 |
