Cooling water relay LKR 3000
The device is used for moitoring cooling water circuits. Because of the high braking capacity thermostats and cryostats are also connectable. A reliable water flow sensor.
- Specifications
- Plastic housing (W x H x D): 160mm x 82mm x 130mm
- LED indication: 10mm high, green
- Adjustment: min. 10 L/h up to max 250 L/h
- Power supply: 230V / 50Hz, 16A
- Breaking capacity: 16A/230V for consumer load, 1A/230V for magnetic valve
Toote variatsioonid
| Description | Catalog number | PK | Kogus | |
|---|---|---|---|---|
| Cooling water relay LKR 3000 | 9.234 295 | 1.00 | ||
| Water stop valve | 9.234 297 | 1.00 | ||
| Flow sensor | 9.234 296 | 1.00 |
