Highly dynamic temperature control systems PRESTO™, air-cooled
- With air-cooled refrigerating machine
- A 38, A 41, and A 70 with natural refrigerants
Toote variatsioonid
| Catalog number | PK | Ext. depth | Ext. height | Ext. width | Heating capacity | IP code | Max. flow rate | Max. temperature | Max. voltage | Min. temperature | Temp. Stability | Type | Weight | Refrigerant | External dimensions (WxDxH) | Power supply | Temperature | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4.686 941 | 1.00 | 750 mm | 670 mm | 330 mm | 2.7 kW | IP 20 | 250 °C | 230 V | -45 °C | ±0,01 ... ±0,05 °C | A 38 | 80 kg | R1270 | 330 x 750 x 670 mm | 230 V, 50 Hz | -45 ... 250 °C | |||
| 9.857 915 | 1.00 | 590 mm | 620 mm | 250 mm | 2.7 kW | IP 21 | 250 °C | 230 V | -30 °C | ±0,01 ... ±0,05 °C | A 30 | 62 kg | R452A | 250 x 590 x 620 mm | 230 V, 50 Hz | -30 ... 250 °C | |||
| 4.658 068 | 1.00 | 1080 mm | 1250 mm | 610 mm | 6 kW | IP 20 | 250 °C | - | -85 °C | ±0,05 ... ±0,1 °C | A 85 | 365 kg | - | 610 x 1,080 x 1,250 mm | - | -85 ... 250 °C | |||
| 9.857 916 | 1.00 | 590 mm | 670 mm | 330 mm | 2.7 kW | IP 21 | 250 °C | 230 V | -40 °C | ±0,01 ... ±0,05 °C | A 40 | 79 kg | - | 330 x 590 x 670 mm | 230 V, 50 Hz | -40 ... 250 °C | |||
| 4.686 942 | 1.00 | 750 mm | 670 mm | 330 mm | 2.7 kW | IP 20 | 250 °C | 230 V | -45 °C | ±0,01 ... ±0,05 °C | A 41 | 80 kg | R1270 | 330 x 750 x 670 mm | 230 V, 50 Hz | -45 ... 250 °C | |||
| 4.672 123 | 1.00 | 665 mm | 1260 mm | 530 mm | 12 kW | IP 20 | 250 °C | - | -45 °C | ±0,05 ... ±0,1 °C | A 45t | 210 kg | R452A | 530 x 665 x 1,260 mm | - | -45 ... 250 °C | |||
| 9.857 918 | 1.00 | 650 mm | 1260 mm | 430 mm | 1.8 kW | IP 20 | 250 °C | 230 V | -80 °C | ±0,01 ... ±0,05 °C | A 80 | 164 kg | - | 430 x 650 x 1,260 mm | 230 V, 50 Hz | -80 ... 250 °C | |||
| 9.857 920 | 1.00 | 650 mm | 1260 mm | 430 mm | 3.4 kW | IP 20 | 250 °C | - | -80 °C | ±0,01 ... ±0,05 °C | A 80t | 167 kg | - | 430 x 650 x 1,260 mm | - | -80 ... 250 °C | |||
| 4.686 943 | 1.00 | 640 mm | 880 mm | 570 mm | 1.8 kW | IP 20 | 250 °C | 230 V | -75 °C | ±0,01 ... ±0,05 °C | A 70 | 140 kg | R449A | 570 x 640 x 880 mm | 230 V, 50 Hz | -75 ... 250 °C | |||
| 4.672 122 | 1.00 | 665 mm | 1260 mm | 530 mm | 6 kW | IP 20 | 250 °C | - | -45 °C | ±0,05 ... ±0,1 °C | A 45 | 210 kg | R452A | 530 x 665 x 1,260 mm | - | -45 ... 250 °C |
