Sand bath SD with performance control and connection cable
For continuous operation. Electrical sand bath with stepless power control. Anodised aluminium alloy hotplate. Excellent uniform temperature distribution over the entire heating surface. The sand bath frame is tightly screwed onto the hotplate so that the sand is in direct contact with the hotplate. Useful depth 50 mm. Stainless steel controller housing, with painted central section. Height-adjustable feet. Connection cable approximately 1.7 m with earthed plug.
Toote variatsioonid
| Depth int. | Display | External dimensions (WxDxH) | Ext. depth | Ext. height | Ext. width | Heating capacity | Height int. | Internal dimensions (WxDxH) | Int. width | Max. temperature | Max. voltage | Min. temperature | Operation | Catalog number | Plug type | Power supply | Temperature | Temperature | Type | Type of display | Weight | PK | Kogus | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 510 mm | Analogue | 364 x 514 x 220 mm | 514 mm | 220 mm | 364 mm | 2850 W | 50 mm | 360 x 510 x 50 mm | 360 mm | 370 °C | 230 V | 5 °C | Rotary knob | 9.645 803 | EU | 230 V | RT | RT+5 ... 370 °C | SD 8 | Without display | 21 kg | 1.00 | ||
| 360 mm | Analogue | 358 x 358 x 220 mm | 358 mm | 220 mm | 358 mm | 2200 W | 50 mm | 360 x 360 x 50 mm | 360 mm | 370 °C | 230 V | 5 °C | Rotary knob | 9.645 801 | EU | 230 V | RT | RT+5 ... 370 °C | SD 7 | Without display | 13 kg | 1.00 |
